Body-
Epoxy Coated Die Cast Aluminum
Gasket-
Thermoplastic Elastomer
Handle-
Polyamide
Lever-
Stainless Steel
ILME Series-
CH
Housing Type-
Standard
Insert Dimension-
77.27
Enclosure Dimension-
77.27
Temperature Range-
-40 C to +125 C
Enclosure Type-
1 Lever w/ Cover
Mounting Style-
Bulkhead Mount
Gasket-
Yes
Ingress Protection-
IP 65 when attached and locked down
Insert Center Distance-
77.5 x 27 mm
Approvals-
C UR US, CCC, GL
